11
English
SPECIFICATIONS
*1 Be sure to check the nameplate on product as it is subject to change by areas.
*2 Weight: According to EPTA-Procedure 01/2003
STANDARD ACCESSORIES
(1) Plastic case .................................................................. 1
(2) Side handle ................................................................. 1
(3) Depth gauge ............................................................... 1
Standard accessories are subject to change without
notice.
ROTARY HAMMER SAFETY WARNINGS
1. Wear ear protectors
Exposure to noise can cause hearing loss.
2. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
3. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own
cord. Cutting accessory contacting a "live" wire may
make exposed metal parts of the power tool "live"
and could give the operator an electric shock.
4. Do not touch the bit during or immediately after
operation. The bit becomes very hot during
operation and could cause serious burns.
5. Before starting to break, chip or drill into a wall,
floor or ceiling, thoroughly confirm that such items
as electric cables or conduits are not buried inside.
6. Always hold the body handle and side handle of
the power tool firmly. Otherwise the counterforce
produced may result in inaccurate and even
dangerous operation.
7. Wear a dust mask
Do not inhale the harmful dusts generated in drilling
or chiseling operation. The dust can endanger the
health of yourself and bystanders.
Model DH24PH DH26PC DH28PCY
Voltage (by areas)*
1
(110 V, 115 V, 120 V, 127 V, 220 V, 230 V, 240 V)
Power Input*
1
730 W 830 W 850 W
No-load speed*
1
0 – 1050 min
–1
0 – 1100 min
–1
Full-load impact rate 0 – 3950 min
–1
0 – 4300 min
–1
Capacity: concrete 3.4 – 24 mm 3.4 – 26 mm 3.4 – 28 mm
steel 13 mm 13 mm 13 mm
wood 32 mm 32 mm 32 mm
Weight*
2
2.7 kg 2.8 kg 2.9 kg
01Eng_DH24PH_EE 4/19/13, 11:3811
