15
EN
Notes:
Optimum performance levels when using the “Express” cycles
can be achieved by respecting the specified number of place
settings.
To reduce consumption even further, only run the dishwasher
when it is full.
Note for Test Laboratories: for information on comparative EN
testing conditions, please send an email to the following address:
assistenza_en_lvs@indesitcompany.com
Special wash cycles
and Options
Wash options*
If an option is not compatible with the selected wash cycle
(see table of wash cycles), the corresponding LED flashes
rapidly 3 times and beeps will sound.
* Only available in selected models.
Multi-functional tablets Option (Tabs)
This option optimises washing and drying results.
When using multi-functional tablets, press the MULTI-
FUNCTIONAL TABLETS button; the corresponding symbol
will light up. If the button is pressed again, the option will be
deselected.
The “Multi-functional tablets” option results in a
longer wash cycle.
Half load Option using the upper or lower rack
If there are not many dishes to be washed, a half load
cycle may be used in order to save water, electricity
and detergent. Select the wash cycle and then press the HALF
LOAD button: the indicator corresponding to the chosen rack
lights up and the wash cycle starts only in the upper or lower rack.
Remember to load the upper or lower rack only, and to
reduce the amount of detergent accordingly.
Delayed start Option
The start of the wash cycle may be delayed for a period
of time between 1 and 12 hours.
1. Press the DELAYED START button: the corresponding symbol
appears on the display; each time you press the button, the time
(1h, 2h, etc. up to max. 12h) from the start of the selected wash
cycle will be increased.
2. Select the cycle and close the door: the timer will begin
counting down;
3. Once this time has elapsed, the indicator light switches off
and the wash cycle begins.
To adjust the delay time and select a smaller period of time,
press the DELAYED START button. To cancel it, press the
button repeatedly until the selected delayed start indicator light
switches off. The wash cycle will start automatically as soon as
the door is shut.
The Delayed Start function cannot be set once a wash
cycle has started.
START 2END LIGHT*
Some dishwasher models are equipped with a green
indicator light in the gap between the door and kitchen
top providing information on the phase of the current
wash cycle. One of the following operating modes can be
selected:
a) Disabled function
b) When the cycle starts the light goes on for few seconds,
stays off during the cycle and flashes at the end of the cycle
(default mode)
c) The light stays on during the cycle and flashes at the end
of the cycle.
If the delayed start was set, the light goes on either for the
first few seconds or the entire duration of the countdown,
based on whether mode b) or c) was set.
The light goes off every time the door is opened.
To select the mode you prefer, switch on the machine, hold
down button P until one of the three letters (a, b or c) ap-
pears on the display, press button P until you reach the
desired letter (or mode), hold down button P to confirm the
selection.
