Microlab MD112 White [5/16] Operation

7

EN

Technical Information

Operation

1. Switch on the power on the MD112 by positioning the level to SD, or FM mode.

2. Ensure all the connections are correctly inserted.

3. To listen music from your media player or notebook, please ensure the 3.5mm audio

input is plugged in.

4. Start the playback device and adjust the volume to your preferred listening level.

forward the playback track.

8. Depress the REW button to skip backward the track. Depress for several

seconds to fast reverse the playback track.

9. Depress the Play button to start the playback, or stop during a playback

function.

10. SD card capacity is supported up to 32 GB size in storage.

11. The SD slot is recognized as a "Removable Disk" in Windows operating

system. Connect the speaker to the notebook via USB cable and the SD card contents

are read in the operating system. This allows complete file management to be carried

out on the SD storage with ease. Copy, move, and even rename your music files from

MHZ. Up to 20 preset stations will be automatically saved. During scanning, the blue

LED will blink rapidly. If a station is found, the blue LED will remain steady.

15. To scan the stations, depress the FW button for several seconds and it will scan the

higher frequencies till it receives the next station in strength. Depress the FW button

higher frequencies till it receives the next station in strength. Depress the FW button

once, and it will jump 100 kHz upward the range.

16. Depress the REW button for several seconds to scan downward the frequency

range. Depress REW button once and it will jump backward 100 kHz downward the

range.

17. To end the playback or broadcast, switch the power level to off position.

Signal/Noise ratio, dB

Input sensitivity, mV

Tweeter driver type

Tweeter rated power

Output

Input

Product dimensions mm

Product Net weight kg
