BPM Matching

So how does one go about doing a DJ set with only one turntable? It is a little different than doing it in Standard mode,

primarily due to the fact that you must use Torq’s on-screen Speed sliders to match tempos as opposed to using the pitch

sliders on your turntable or CD player.

Try it out: Click Vinyl on a Deck and start the external control source. While the song is playing, move the Deck’s on-

screen Speed slider. Sure enough—the playback speed of the song changes, just as if you’d moved the pitch slider on the

actual turntable or CD player.

The reason for requiring the use of the on-screen controls lies in the fact that external control can be toggled back and

forth between the Decks at will. Any time you do this, you’ll want the Decks to keep their previous tempos. If the tempo

of a Deck changed when swapping external control, the mix would suddenly fall wildly out of sync.

Therefore, the speed of the Control Vinyl or Control CD must remain constant—Torq will scale the playback rate as

appropriate based on the setting of the Decks’ Speed sliders. If you change the speed of the control source, you’ll ﬁnd

that the Decks suddenly change speed any time you toggle external control.

There is, however, one unique advantage to this setup: you can make use of Torq’s automatic beat-matching! Instead

of manually moving the on-screen Speed slider with the mouse or MIDI Control, you can simply click the Deck’s Sync

button and it’s Speed slider will be moved to match the tempo of the other Deck. Click the Sync button again to turn it

off, and the Deck will remain at the proper speed waiting for the external control signal to begin. All you have to do then

is start the music at the right time and keep it in alignment during the mix via external control. This makes the process of

preparing the next track much faster.

Runout Protection

Since there is only about 12 minutes of usable control signal on each side of the Control Vinyls or on each track of the CD,

it is possible that the song you are controlling could exceed the length of control signal available on the record or CD. This is

extremely common when using Relative mode since the needle or CD position could be halfway through when you start the

next track.

In order to prevent the music from stopping abruptly if the control signal runs out on the record or CD, Torq features Runout

Protection which essentially disables External Control when the record or CD reaches the last 30 seconds of its signal. When

this happens, the song’s waveform will start to ﬂash yellow and the song on the Deck continue to play. You will now be able

to take the needle off the record and place it back at the beginning without Torq stopping the music (the same is true for the

CD—you can jump back to the beginning of the track without stopping the music). Once Torq reads a few seconds of signal

from the new location, the ﬂashing will stop and Torq will re-engage External Control allowing you to scratch and manipulate

like normal.

✓ Note: If you are currently in Absolute mode when the last 30 seconds of control signal are reached, Torq will automatically

switch the Deck into Relative mode when it engages the Runout Protection. The Deck will remain in Relative mode after you

reset the record or CD, thus preventing the music from jumping to an unexpected location when external control is enabled

again.

MIDI Control

While the Torq Control Vinyl and Control CDs offer a great way to control song playback on the Decks, there are still plenty

of other features in Torq that would surely feel good under the ﬁngertips. For that purpose, Torq provides the option of MIDI

control for nearly every button, knob, and slider on the interface. Since MIDI is a common protocol shared between all types of

musical gear, you can use almost anything capable of generating MIDI note or CC messages to control Torq—they do not need

to be specialized DJ controllers. This will offer you a way to experiment with different control methods when DJing, such as

using an M-Audio Trigger Finger to control samples or an M-Audio Axiom 25 keyboard to control effects and pitches.
