Sample Name Window

The Sample Name window serves multiple purposes.

1. It will display the name of the sample ﬁle loaded into the slot.

2. The background of this window will ﬁll from left to right as the sample plays, like a progress meter.

3. Clicking on this window will display a pop-up menu with the following options:

< Load Sample

Choosing this option will open a standard dialog box. Use this dialog to navigate to your hard drive and

locate a sample. If you load a sample into a slot that already has a sample loaded, the current sample will be

immediately replaced.

< Save Sample

Choosing this option opens a standard Save dialog box. Use this dialog to name the current sample and save it

to a speciﬁc location. The new name will also be displayed in the Sample Name window.

✓ Note: This option will be unavailable (grayed out) if the sample slot is empty.

< Rename Sample

Once you’ve recorded a sample, you can rename it from the generic “SampleXXX” naming format

automatically applied to new samples. Simply click this option in the menu and type in a new name for the

sample. The ﬁle on your hard drive will be renamed to match.

✓ Note: This option will be unavailable (grayed out) if the sample slot is empty.

< Unload Sample

Choosing this option will remove the current sample from the sampler.

< Load Sample Bank

This option will allow you to load a bank of 16 samples into the Sampler using only one action. Choosing this

option opens a standard dialog box that looks only for “.tsb” (Torq Sample Bank) ﬁles. Browse your hard drive

and select a .tsb ﬁle. Torq will read this ﬁle and load the required sample ﬁles into the appropriate slots. It will

then set the playback parameters for each sample.

✓ Note: This operation will replace any samples that are currently loaded into the Sampler. If you want to keep

the current conﬁguration, save the bank (using the procedure below) before loading a new bank.

< Save Sample Bank

Once you have built a collection of samples (drum loops of a particular style or a collection of vocal stabs, for

example), you can save the collection as a sample bank. Choosing this option from the menu opens a standard

Save dialog box that will save a proprietary Sample Bank ﬁle. This ﬁle references the samples currently loaded

into the Sampler. Browse to your hard drive and choose a location to save the ﬁle. The ﬁle will be saved with

the extension “.tsb” (Torq Sample Bank). A ﬁle folder will also be created (of the same name) but with the

word “Samples” appended to the end. This “Samples” folder will contain copies of the samples used in the

bank for easy recall in the future.
