27 -
Operating modes – EPG
When receiving digital terrestrial and digital satellite stations, you may find that
two identical EPG data are displayed in the “EPG (DVB)“ menu for one station. If
you call the EPG menu in the EPG mode by using the MENU button, then select
“Station selection,“ you can select the duplicate station and deactivate it by using
OK).
You have direct access to the selection lines above to pre-select the day, the time,
the station and the topic.
Blue coloured key: Call Select date/time/stations/topics
Use to select the menu line for the date, time, stations or topics. Use
to select within the menu line.
If, for example, you are looking for the next news, select today’s date, “Soon“
under Time, “All“ under Stations and “News“ under Topics.
Then you get a list of all news programmes in the programme list below.
If you want to mark one of these news programmes, return to the programme list
using the blue coloured key, select the desired news programme by using
and mark this by using OK.
EPG - Programme guide
EPG is an electronic programme guide. With this system, you can easily find the
programmes that interest you (sorted according to day, time, stations and topics).
You can mark programmes and programme recordings.
Depending on whether you are receiving analogue stations by cable/antenna or
digital stations, you will have different programme guides.
A wizard is activated the first time you use EPG (not with DVB) which guides you
through the necessary settings. Then run the data capture (see next page).
Using the EPG
Switch EPG on/off
The programme guide menu is divided into two areas: at the top, you can make the
settings for the programme list (date, ..., topics); on the bottom, the programme list
is displayed. Use the blue coloured key to switch between the two areas to make
your selections.
All programmes currently running are listed initially in the programme list. With the
buttons, select the programme you want to watch and switch over with the
OK button.
Brief information is shown below the programme list for some programmes. If more
detailed information is available, you can call it using the TEXT button.
Use P+/P– to scroll up or down through the pages of the programme guide.
In the selection lines for date and time above, you will see the time change when
scrolling; when you scroll further, the date also changes.
When the “Time“ line is selected, you can enter the time as of which the pro-
grammes are to be displayed; use the numeric buttons on your remote control to do
this. Always enter four digits, such as 0900 for 9 a.m.
If programmes are displayed which have not yet started, you can mark these with the
OK button. The TV set then switches automatically to this station at the given time.
MENU
TEXT
P+
P–
END
OK
OK
Detail View Record
Page
/ select time Select date, ... , topics
EPG (Electronic Programme Guide) Fri 10.09./14:14
Fri 10.09.
now soon 14:00 15:00 16:00 17:
0
all
all
Date
Time
Stations
Topics
13:20-14:15 Kabel 1 Die Waltons
13:30-14:15 H3 ARD-Buffet
13:55-14:20 Kinderkan Blaubär & Blöd (37)
14:00-14:15 ZDF heute - in Deutschland
14:00-15:00 RTL Das Strafgericht
14:00-15:00 Sat 1 Zwei bei Kallwass
14:00-15:00 Pro7 Das Geständnis - Heute s...
14:00-14:30 N3 DAS! ab 2
14:00-14:20 WDR Die kleinen Strolche (10)
Familienserie - Sturzflug
24 Kabel 1
0 9
...
MENU
END
Change to programme list
EPG (Electronic Programme Guide) Fri 10.09./14:14
Sat 11.09. Sun 12.09. Mon 13.09.
06:00
all
all
Date
Time
Stations
Topics
06:00-06:20 ZDF Die Blobs
06:00-06:30 RTL Wunderbare Jahre
06:00-06:25 Kabel 1 Dennis
06:00-06:25 N3 Extra en español (5)
06:00-06:30 BR Goal. Speak English, Play Football
06:00-06:30 WDR Lokalzeit Südwestfalen
06:00-07:10 SuperRTL Infomercials
06:00-07:10 Kinderkan Reif für die Dodo-Insel (25)
14:00-14:20 9LIVE Reisetraum
Comedyserie - Kandidaten mit gewissen Fehlern
24 Kabel 1
MENU
END
Change to programme list
EPG (Electronic Programme Guide) Fri 10.09./14:14
Fri 10.09.
soon
all
News Show Hobby Sport Child Kn
Date
Time
Stations
Topics
15:00-15:15 Das Erste Tagesschau um drei
15:00-15:05 hr-fernse hessen aktuell
15:00-15:15 ZDF heute - Sport
16:00-16:05 SÜDWEST Baden-Württemberg Aktuell
16:00-16:15 Das Erste Tagesschau um vier
Nachrichten - News
24 Kabel 1
BA32789_021XelosModusRel_5_GB.in27 27BA32789_021XelosModusRel_5_GB.in27 27 15.01.2007 16:56:1115.01.2007 16:56:11
