Chapter 3. Wireless Settings | 31

N750 Wireless Dual Band Gigabit Router WNDR4000 User Manual

Wireless Settings Screen Fields

Region

The location where the wireless router is used. It might not be legal to operate the wireless

router in a region other than the regions listed.

Wireless Network (for 2.4 GHz b/g/n and 5 GHz a/n)

The primary network is the one that you usually use. You can set up guest networks too. You

can customize access so that people who use their computers to access your guest network

can use the Internet, but they do not have access to the rest of your home network.

• Enable Wireless Isolation. When this check box is selected, wireless stations cannot

communicate with each other or with stations on the wired network. By default, this check

box is not selected.

• Enable SSID Broadcast. This setting allows the wireless router to broadcast its SSID so

that a wireless station can display this wireless name (SSID) in its scanned network list.

This check box is selected by default. To turn off the SSID broadcast, clear this check box

and click Apply.

• Name (SSID). The SSID is also known as the wireless network name. Enter a

32-character (maximum) name in this field. This field is case-sensitive. The default SSID

for your primary network is randomly generated, and there is typically no need to change

it. If you want to set up guest networks, NETGEAR does recommend that you customize

the default guest network names (SSIDs).

• Channel. The wireless channel used by the gateway: 1 through 13. Do not change the

channel unless you experience interference (shown by lost connections or slow data

transfers). If this happens, experiment with different channels to see which is the best.

• Mode. Up to 150 Mbps is the default and allows 802.11n and 802.11g wireless devices to

join the network. g & b supports up to 54 Mbps. Up to 65 Mbps supports up to 65 Mbps.

Security Options Settings

The Security Options section of the Wireless Settings screen lets you change the security

option and passphrase. NETGEAR recommends that you set up wireless security for your

primary network and wireless router and for each guest network that you plan to use.

• None. You can use this setting to establish wireless connectivity before implementing

wireless security. NETGEAR strongly recommends that you implement wireless security.

• WPA-PSK [TKIP] (WiFi Protected Access Pre-Shared Key). Allow only computers

configured with WPA to connect to the wireless router. When you select this option, this

additional area displays. Enter the WPA passphrase (network key). The passphrase has

to be between 8 and 63 ASCII characters or exactly 64 hex digits.

• WPA2-PSK [AES] (Wi-Fi Protected Access with 2 Pre-Shared Keys). Allow only

computers set up with WPA2 to connect to the wireless router. When you select this

option, this additional area displays. Enter the WPA passphrase (network key). The

passphrase has to be between 8 and 63 ASCII characters or exactly 64 hex digits.
