KeyStudio User Guide

As with Program changes, if the Octave “<” and “>” buttons are selected to vary the Bank LSB or MSB number (Method 1),

the lights above the buttons will not change, since it is not possible to have a Bank with a negative value. Pressing both the

“<” and “>” buttons together will recall Bank 0.

Bank change messages must be followed by a program change message in order to recall a sound. Bank change messages

by themselves do not activate a sound, but only locate and access a predefined location of a set (bank) of 128 sounds.

PLEASE NOTE: Each time the keyboard is turned off, optional MIDI parameters assigned to the Octave buttons will be lost.

valuestohaveanyeffectonthesound,thereceivingsoftwareordevicehastobeabletoreadandrespondtotheseMIDIcontroller

messages. KeyStudio accepts controller numbers 0-131. Numbers beyond 127 are a proprietary method M-Audio uses to simplify

thetransmissionofcertain,otherwisemorecomplicatedmulti-partMIDImessages.Afulllistofcontrollervaluesisgivenattheback

of this manual in Appendix B.

Some useful MIDI CC’s are:

< 01 Modulation

< 07Volume

< 10 Pan (balance)

< 05 Portamento

To assign a MIDI controller message to the Modulation wheel:

Ifyoumakeanerrorwhileenteringthenumericaldatavalue,youcanpresstheCANCELkey(C1)toexitEditmodewithout

changingtheMIDICCassignedtotheModulationwheel.
