MSI 870S-G54 [33/83] Switch

2-18

Hardware Setup

MS-7599

Chapter 2

Hardware Setup

MS-7599

Chapter 2

Swtch

Ths manboard provdes the followng swtch for you to set the computer’s functon.

Ths secton wll explan how to change your manboard’s functon through the use of

swtch.

Easy OC Swtch: OC_SW1 (optonal)

You can overclock the FSB to ncrease the processor frequency by changng the swtch.

Follow the nstructons below to set the FSB.

Default Increase 10%

speed of FSB

Increase 15%

speed of FSB

Increase 20%

speed of FSB

Important

Make sure that you power o the system before settng the swtch.

When overclockng cause system nstablty or crash durng boot. Please set the

swtch to default settng.

•
