Philips HX6022/07 [6/92] English

2 To attach a new ring, slip one edge of the new ring over the bottom

of the brush head. Then press down on the other side to snap the

ring into place.

Attaching the brush head

1 Align the brush head so the bristles face the front of the handle.

2 Firmly press the brush head down onto the metal shaft until it stops.

Note: There is a small gap between the colour code ring and the handle.

Charging the Sonicare

1 Put the plug of the charger in the wall socket.

2 Place the handle on the charger.

The battery charge indicator next to the battery symbol ﬂ ashes to

indicate that the toothbrush is charging.

Battery charge indicator

The battery charge indicator shows the approximate remaining battery

charge.

Deluxe charge indicator (speciﬁ c types only):

Solid green: 50-100%

Flashing green: 10-49%

Flashing yellow: less than 10%

Standard charge indicator (speciﬁ c types only):

Solid green: 50-100%

Flashing green: less than 50%

Note: When the battery is low, you hear 3 beeps after the completion of the

brushing cycle and the battery charge indicator ﬂ ashes for 30 seconds.

Note: To keep the battery fully charged, you may keep your Sonicare on the

charger when not in use. It takes 24 hours to charge the battery fully.

Using the Sonicare

Brushing instructions

1 Wet the bristles and apply a small amount of toothpaste.

ENGLISH6
