Philips HX6022/07 [9/92] English

Quadpacer (select models)

The Quadpacer is an interval timer that has a short beep and pause

to remind you to brush the 4 sections of your mouth evenly and

thoroughly.

When you use the two-minute Clean or Sensitive mode, you hear a

short beep and a pause in brushing action at 30, 60 and 90 seconds.

When you use the Clean and White mode, you hear and feel a change

in the brush head sound and motion after 2 minutes of Clean mode.

Then move the brush head to the visible upper front teeth and brush

them for 15 seconds. At the ﬁ nal beep and pause, move to the visible

lower front teeth and brush them for 15 seconds.

Cord wrap facility (speciﬁ c types only)

If your Sonicare type includes the deluxe charger cover and base, the travel

charger is pre-installed inside the cover. If you want to shorten the mains

cord, you can store excess cord in the cord wrap facility in the charger

base.

1 To separate the charger cover from the charger base, press the two

grey snap bars on the charger base and pull the white charger cover

upwards.

2 Wrap excess mains cord around the grey charger base as shown in

the picture. Make sure you wrap the cord on the inside of the two

snap levers.

3 When you have stored the excess cord, guide the mains cord

through the small groove in the rear of the grey charger base.

4 To reattach the charger cover, press it down over the charger base

until it snaps into place.

Tip: For extra convenience during travel, you can remove the travel charger and

use it without the charger cover and charger base.

ENGLISH 9
