Bork SF TOR 2355 SI [16/24] Assemble

Stand Fan SF TOR 2355 SI

ASSEMBLE

COMPLETE SET

Stand Fan 1

Instruction Manual 1

 Unscrew two screws from the pole of the stand set. Insert the

pole into the motor assembly and secure the pole with the two

screws.

 Using M4 screws to secure the base with the stand set.

 Remove the grill nut and blade knob from the motor assembly.

Mount the back grill on to the motor unit by matching the three

holes on the back grill the the three round pins on the front of the

motor units. Push in firmly until the three pin protrudes through

the three holes.

 Secure the back Grill to the Motor unit with the Grill Lock:

clockwise.

 Align the Motor Shaft with the “D”shaped hole of the Fan Blade.

Fully insert the Motor shaft into the Fan Blade, then secure with

the Blade Knob, turning counter-clockwise. Do not over tighten .

 Take the Front Grill. Open the clip by moving the lip of the clip

downwards. Attach the Front Grill to the Back grill by positioning

the Hook. Join the two Grills by pressing firmly (Click). Secure the

two grills by moving the clip upwards.

 To adjust the fan’s height, loosen the Height adjustment Knob

by unscrewing counter-clockwisely a few turns. Pull upwards on

the chrome portion of the Pole Assembly while holding the lower

portion firmly to raise the Height, or push down on the chrome

portion to lowerthe height. Retighten the Height Adjustment Knob,

be careful not to over tighten.
