Tp-Link TL-SG2008 [38/153] Port security

Note:

1. The LAG member can not be selected as the mirrored port or mirroring port.

2. A port can not be set as the mirrored port and the mirroring port simultaneously.

3. The Port Mirror function can take effect span the multiple VLANs.

5.1.3 Port Security

MAC Address Table maintains the mapping relationship between the port and the MAC address of

the connected device, which is the base of the packet forwarding. The capacity of MAC Address

Table is fixed. MAC Address Attack is the attack method that the attacker takes to obtain the

network information illegally. The attacker uses tools to generate the cheating MAC address and

quickly occupy the MAC Address Table. When the MAC Address Table is full, the switch will

broadcast the packets to all the ports. At this moment, the attacker can obtain the network

information via various sniffers and attacks. When the MAC Address Table is full, the packets

traffic will flood to all the ports, which results in overload, lower speed, packets drop and even

breakdown of the system.

Port Security is to protect the switch from the malicious MAC Address Attack by limiting the

maximum number of MAC addresses that can be learned on the port. The port with Port Security

feature enabled will learn the MAC address dynamically. When the learned MAC address number

reaches the maximum, the port will stop learning. Thereafter, the other devices with the MAC

address unlearned can not access to the network via this port.

Choose the menu Switching→Port→Port Security to load the following page.

Figure 5-4 Port Security

The following entries are displayed on this screen:

¾ Port Security

Select: Select the desired port for Port Security configuration. It is

multi-optional.

Port: Displays the port number.
