Tp-Link T1700X-16TS [6/28] Chapter 1 introduction

JetStream 10-Gigabit Smart Switch

Introduction

Chapter 1 Introduction

1.1 Product Overview

TP-LINK 10-Gigabit Smart Switch provides wire-speed performance and abundant L2

and L2+ management features. It provides a variety of service features and multiple

powerful functions with high security. With the 10-Gigabit Smart Switch, you can create

high-speed connections to a server or network backbone, connect switches to each

other with high-speed links, link to high-speed servers, or provide 10G copper and fiber

connectivity.

You can use Category 5e (CAT 5e) or better Ethernet cable (CAT 6, CAT 6a, or CAT 7)

to make 10G connections. TP-LINK recommends that you use CAT 6a or CAT 7 cables if

the cable distance is greater than 148 feet (45 meters).

The EIA-standardized framework and smart configuration capacity can provide flexible

solutions for a variable scale of networks. QoS and IGMP snooping/filtering optimize

voice and video application. Link aggregation increases aggregated bandwidth,

optimizing the transport of business critical data. SNMP, RMON, WEB and CLI Log-

in bring abundant management policies. TP-LINK 10-Gigabit Smart Switch integrates

multiple functions with excellent performance, and is friendly to manage, which can

fully meet the need of the users demanding higher networking performance.

1.2 Appearance

■

Front Panel

The front panel of T1700X-16TS is shown as the following figure.

Reset

LEDs Indication

100M/1000M/10Gbps RJ45 Port

1G/10Gbps SFP+ Port

LEDs

Figure 1-1 Front Panel of T1700X-16TS

LEDs

LED Status Indication

PWR

On The switch is powered on

Off The switch is powered off or power supply is abnormal

Flashing Power supply is abnormal

SYS

Flashing The switch is working normally

On/Off The switch is working abnormally
