SOHO & SMB Solutions
CS231
Computer Sharing Device (USB)
Specifi cation
Features
The CS-231 is a powerful, micro-processor
controlled computer sharing device. It is
a multi-user, single-tasking device that
enables two users to share the use of a single
computer - each from their own consoles
(monitor, keyboard, and mouse). The CS-231
supports USB consoles and both PS/2 and USB
computers.
• Single computer shared by two USB consoles
• Supports USB and PS/2 computers
• Multiplatform Support (Windows, Mac, Unix and Linux)
• Manual or Auto console selection
• Control the system with Hotkeys
• Firmware upgradable
• Private Mode for a privileged user
• Screen Saver function
• Choose from four Timeout settings
• Supports VGA, SVGA, and MultiSync monitors
• No software required
Function CS-231
Computer Connections 1
Console Connections 2
Console Selection Pushbutton, Hotkey
Connectors
Console
Ports
Keyboard
2 x USB Type A Female
(White)
Video 2 x HDB-15 Female (Blue)
Mouse
2 x USB Type A Female
(White)
Computer Port
1 x SPHD-15/18 Female
(Green)
F/W Upgrade 1 x RJ-11 Female (Black)
Power 1 x DC Jack (Black)
Switches
Mode Selection 1 x Pushbutton
Reset 1 x Semi-recessed Pushbutton
DIP 1 x 4 pin
LEDs
Mode 1 (Orange)
Selected 2 (Green)
Video 1920x1440@60Hz, DDC2B
Timeout Settings 5, 60, 125, 255 Seconds
Power Consumption DC5.3V, 2.2 W (Max.)
Environment
Operating Temp. 0-50˚C
Storage Temp. -20-60˚C
Humidity 0-80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.56 kg
Dimensions
(L x W x H)
14.00 x 8.80 x 5.55 cm
* The specifi cations and pictures are subject to change without notice.
or
PS/2 Computer
USB Computer
USB Console 2
USB Console 1
CS231(Rear)
