Aten CS231 Руководство пользователя онлайн
User Manual
CS-231
Read this guide thoroughly and follow the installation and
operation procedures carefully in order to prevent any damage to
the units and/or any devices that connect to them.
This package contains:
1 CS-231 Computer Sharing Device
1 USB KVM Cable
1 Power Adapter
1 Firmware Upgrade Cable
1 DIP Switch Sticker
1 User Manual
1 Quick Start Guide
If anything is damaged or missing, contact your dealer.
© Copyright 2005-2006 ATEN
®
International Co., Ltd.
Manual Part No. PAPE-1290-100G
Printing Date: 11/2006
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights
reserved. All other trademarks are the property of their respective owners.
