Installation

Installing your new CS-231 involves the following seven steps

(refer to the diagram on the following page):

1. Connect the 15-pin SPHD connector on the KVM cable to

the PC port on the CS-231.

2. Connect the VGA video connector on the KVM cable to the

VGA video output port on the computer. Plug the USB

connector into any available USB port.

3. Plug the keyboard, mouse and monitor for the console that

you want to designate as Console 1 into the Console 1 ports.

4. Plug the keyboard, mouse and monitor for the console that

you want to designate as Console 2 into the Console 2 ports.

5. Set the DIP switch (see DIP Switch Settings Table, page 11,

for details).

6. Plug the power adapter into an AC power source; plug the

power adapter cable into the power jack on the CS-231.

7. Power on the computer and monitors.

1. Make sure that power to all the devices you will be

connecting up has been turned off. You must

unplug the power cords of any computers that

have the Keyboard Power On function.

2. To prevent damage to your equipment, make sure

that all devices you will be connecting up are

properly grounded.
