- 11 -
the Console 2 user strikes the keyboard or moves the
mouse, the OSD message is displayed again.
To exit Private Mode:
1. From the keyboard of Console 1, press the Shift key six
times within 2 seconds; or, press the MANUAL/AUTO
Button.
Screen Saver
To protect the screen phosphors, when the CS-231 is in Auto
Mode and no one is accessing the computer, a stripe image can
scroll down the screen. To enable this function, set DIP switch pin
4 to the On position.
DIP Switch Settings Table
Note: Press a DIP switch pin down to turn it on, up to turn it off.
Manual Mode
Manual Mode is used to access the computer for a longer period
of time. It is invoked by repeatedly pressing the MANUAL/AUTO
Button to bring the focus to the desired console as follows:
DIP Switch Pins Function
1 2 3 4
On On X X 5 Second Timeout
Off On X X 60 Second Timeout
On Off X X 125 Second Timeout
Off Off X X 255 Second Timeout
X X On X Private Mode Enabled
X X Off X Private Mode Disabled
X X X On Screen Saver Enabled
X X X Off Screen Saver Disabled
