- 12 -

Auto Mode > Console 1 > Console 2 > Auto Mode

 When Manual Mode is invoked, the CS-231 switches to the

selected console and prohibits the other console from

controlling the computer. The selected console retains control

until the MANUAL/AUTO Button is pressed again.

 A message appears on the other user’s monitor indicating that

the system is in use. After 10 seconds, the message

disappears and the user can view the computer display. If the

user strikes the keyboard or moves the mouse, the OSD

message is displayed again.

 The user who has control of the computer can prevent the

other user from viewing the computer display by entering the

following Hotkey combination:

[Num Lock]+[-],[D]

If the other user strikes the keyboard or moves the mouse, a

message appears indicating that the system is in use. After

10 seconds, the message disappears and the monitor

displays a black background. If the user strikes the keyboard

or moves the mouse, the OSD message is displayed again.

To switch to the other console, repeatedly press the Manual/Auto

Mode Button until the desired console controls the device, or

enter the following hotkey combination:

[Scroll Lock], [Scroll Lock], [Enter]

Note: If using the Scroll Lock key conflicts with other programs

running on the computer, the Ctrl key can be used

instead. See HSM Summary Table, page 13, for details.

Hotkey Setting Mode

Hotkey Setting Mode is used to configure your CS-231 switch. All

operations begin with invoking Hotkey Setting Mode (HSM).
