Aten CS1792 Описание и спецификации продукта онлайн
ATEN International Co., Ltd.
3F., No.125, Sec. 2, Datong Rd., Sijhih District., New Taipei City 221, Taiwan
Phone: 886-2-8692-6789 Fax: 886-2-8692-6767
www.aten.com E-mail: marketing@aten.com
© Copyright 2014 ATEN® International Co., Ltd.
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd.
All rights reserved. All other trademarks are the property of their
respective owners.
Printed 05/2014 V7.0
SOHO & SMB Solutions
CS1792 / CS1794
USB 2.0 HDMI KVMP™ Switch
Specifi cation
Features
With its unique design and innovative features, the CubiQ CS1792/
CS1794 USB 2.0 HDMI KVMP™ Switch provides both style and
functionality for today’s multimedia SOHO environment.
Combining a 2/4-port switch with a 2-port USB 2.0 hub, the CS1792/
CS1794 provides seamless HDMI signal switching between 2/4 PCs
or other HDMI-enabled devices, such as gaming consoles, and allows
users to share USB peripherals from a single console. The CS1792 /
CS1794 provides enhanced independent switching via front panel
pushbuttons and keyboard hotkeys, and features Video DynaSync
technology to ensure that HDMI display resolution is always optimized.
With integrated digital audio, the CS1792/CS1794 also allows users to
experience high-defi nition sound, such as Dolby True HD and DTS HD
Master Audio.
Ideal for multimedia applications in the home or office, the CubiQ
CS1792/CS1794 offers the ultimate in space-saving, streamlined KVM
technology for the desktop.
• 2/4-port HDMI USB 2.0 KVMP™ Switch
• One USB console controls two (CS1792) or four (CS1794) HDMI-interface
computers and two additional USB devices
• 2-port USB 2.0 hub built in; fully compliant with the USB 2.0 specifi cation
• Independent switching of KVM, USB peripheral, and audio focus via front panel
pushbuttons and hotkeys
• HDMI digital and analog monitor support – fully compliant with HDMI; also
HDCP compliant
• Dolby True HD and DTS HD Master Audio support
• Superior video quality—supports 480i, 480p, 720p, 1080i, and
1080p(HDTV)/1920 x 1200(DVI)
• Power on detection – If one of the computers is powered off, the CS1792 /
CS1794 will automatically switch to the next powered-on computer
• Supports widescreen resolutions
• Multiplatform support – Windows, Linux, and Mac
• Console mouse port emulation/bypass feature supports most mouse driver and
multifunction mice
• Video DynaSync™ – stores the console monitors EDID (Extended Display
Identifi cation Data) to optimize display resolution
• Complete keyboard emulation for error-free booting
• Mac keyboard support and emulation*
• Auto Scan Mode for monitoring all computers and HDMI devices
• Firmware Upgradable
* 1.PC keyboard combinations emulate Mac Keyboards
2.Mac keyboards only work with their own computers
USB 2.0
Peripherals
2 Port
Win, Mac, Linux
HDMI
HDMI
Wide
Screen
Support
Video
DynaSync
Function CS1792 CS1794
Computer Connections 2 4
Port Selection Front Panel Pushbuttons; Hotkeys
Connectors
Console
Ports
Keyboard 1 x USB Type A Female (Black; rear panel)
Video 1 x HDMI Type A Female (Black)
Mouse 1 x USB Type A Female (Black; rear panel)
Speaker 2 x Mini Stereo Jack Female (Green; 1 x front, 1 x rear)
Mic. 2 x Mini Stereo Jack Female (Pink; 1 x front, 1 x rear)
KVM
Ports
Keyboard /
Mouse
2 x USB Type B Female
(White)
4 x USB Type B Female
(White)
Video
2 x HDMI Type A Female
(Black)
4 x HDMI Type A Female
(Black)
Speaker
2 x Mini Stereo Jack Female
(Green)
4 x Mini Stereo Jack Female
(Green)
Mic.
2 x Mini Stereo Jack Female
(Pink)
4 x Mini Stereo Jack Female
(Pink)
F/W Upgrade 1 x 4-conductor 3.5 mm Jack (Black)
Power 1 x DC Jack
USB 2.0 Hub
2 x USB Type A Female
(White; 1 x front panel; 1 x rear panel)
Switches Selected 3 x Pushbutton 5 x Pushbutton
LEDs
Audio 3 (Green) 5 (Green)
KVM 3 (Orange) 5 (Orange)
USB
3 (Green) 5 (Green)
Emulation Keyboard / Mouse USB
Video 1080p (HDTV) / 1920 x 1200 (DVI)
Scan Interval 1–99 secs. (Default: 5 secs)
Power Consumption DC 5.3 V, 3.2 W DC 5.3 V, 4.8 W
Environment
Operating Temp. 0–50ºC
Storage Temp. -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal, Plastic
Weight 0.42 kg 0.53 kg
Dimensions
(L x W x H)
20.63x7.24x4.56cm 26.20x7.24x4.56cm
* Product specifi cations and appearance are subject to change without notice.
VDS
(Rear)
Game Console
