Chapter 1. Introduction
3
Features
2/4-port HDMI USB 2.0 KVMP Switch
One USB console controls two (CS1792) or four (CS1794) HDMI-
interface computers and two additional USB devices
2-port USB 2.0 hub built in
Fully compliant with the USB 2.0 specification
Independent switching of KVM, USB peripheral, and audio focus
HDMI digital monitor support – fully compliant with HDMI; also HDCP
compliant
Dolby True HD and DTS HD Master Audio support
Superior video quality – supports 480i, 480p, 720p, 1080i, and 1080p
(1920 x 1200)
Supports widescreen resolutions
Computer selection via front panel pushbuttons and hotkeys
Multiplatform support – Windows 2000/XP/Vista, Linux, and Mac
Console mouse port emulation/bypass feature supports most mouse
drivers and multifunction mice
Video DynaSync – stores the console monitors EDID (Extended Display
Identification Data) to optimize display resolution
Power on detection – if one of the computers is powered off, the CS1792 /
CS1794 will automatically switch to the next powered-on computer
Complete keyboard emulation for error-free booting
Mac keyboard support and emulation*
Auto Scan Mode for monitoring all computers and HDMI devices
Firmware Upgradable
* 1. PC keyboard combinations emulate Mac keyboards.
2. Mac keyboards only work with their own computers
