Altusen™ Enterprise Solutions

ATEN is well known for delivering innovative technologies that drive connectivity and access management

solutions. As such, we introduce the new Altusen™ KE6900 / KE6940 DVI KVM Over IP Extender that brings

together a unique blend of features and new technologies that offer the ultimate solution for extending

computers to consoles on or off your IT infrastructure.

Utilizing expertise in Over IP KVM solutions, the KE6900 / KE6940 series is an IP based DVI KVM Extender that

allows access to a computer system from a remote USB console (USB keyboard, USB mouse, DVI monitor)

anywhere over an intranet. The KE6900 Single View Extender supports one DVI display at each end. The

KE6940 Dual View Extender supports two DVI displays at each end, allowing the video output to display on two

monitors.

The DVI KVM Over IP Extender consists of a Transmitter unit that connects to the computer and a Receiver unit

that provides console access from a separate location. The computer is accessed from the remote console over

a standard TCP/IP network via Cat 5e cable that allows point-to-point, point-to-multipoint, and multipoint-to-

multipoint administration. This is perfect for use in any type of installation where you need to place the console

where it is convenient, but you want the computer to reside in a secure location - away from the keyboard,

mouse and display in use. As a Matrix Extender it can connect single/multiple: computers-to-consoles in several

ways: one-to-one (Extender mode), one-to-many (Splitter mode), many-to-one (Switch mode), or many-to-many

(Matrix mode).

The Matrix Manager® software provides advanced features for username/password authentication, auto-

detection of all KE6900 / KE6940 devices on the same subnet and deﬁne connections that can be switched and

shared. New security features also provide extra protection, supporting AES-128bits encryption for secured data

transmission, while RADIUS, LDAP, AD or remote user authentication provides added layer of connection security.

With an OSD, RS-232 support, and Auto MDIX, the KE6900 / KE6940 is the most cost-effective and convenient

way to get a full digital extension from anywhere on the intranet.

KE6900

KE6940

DVI KVM Over IP Extender

KE6940R Front View

KE6940R Rear View

KE6940T Front View

KE6940T Rear View
