CE250A User Manual
2
Features
Cat 5 (or higher) cable to connect the Local and Remote Units – up to 150
m apart
Dual console operation – control your system from both the local and
remote PS/2 keyboard, mouse and monitor consoles
Pushbutton selection of the active console
High resolution video – up to 1280 x 1024 @ 60 Hz
Supports VGA, SVGA, and Multisync monitors – local monitor supports
DDC; DDC2; DDC2B
Supports Microsoft Intellimouse and the scrolling wheel on most mice
Automatic gain control – automatically adjusts signal strength to
compensate for distance
Built-in 8KV ESD protection and 2KV surge protection
Built-in ASIC for greater reliability and compatibility
Local unit takes its power from the computer – external power is only
required when the power from the local computer/computers in the KVM
installation is insufficient*
Rack mountable
Supports Wide Screen formats **
Note: *If you choose to purchase a power adapter for use with the CE250AL,
be sure to get one with the same specifications as the one provided in
this package for the CE250
AR.
**The EDID data for a widescreen is sent from the local video output
port. For widescreen modes and displays connect the monitor to the
local video output port or use an ATEN EDID emulator.
