Enterprise Solutions
4
Dual Power Supply
Dual Power supply operation provides backup redundancy and reliability – ensuring
that down-time is kept at a minimum. Should one of the power supplies become
unavailable, the other will take over in order to keep the system functioning normally.
Power Association
Used in conjunction with ALTUSEN’s Power Over the NET™ power management
device, you can associate a Matrix KVM Switch’s port with a PDU’s power outlet, and
then manage the power operation of a server from the switch’s interface – a single
interface point. It also enables you to associate a second outlet port if the server has
a dual power supply, and lets you synchronize the operation for both power supplies.
In this way, Power Association reduces maintenance time and increases management
efficiency
Flexible Scalability
Matrix KVM Switches can be daisy chained, cascaded, or both in tandem – flexible
expansion configurations allows up to 9 consoles to control thousands of servers.
Add consoles and servers a step at a time to match your company’s growth. Daisy
chaining KM0032 switches offers a further cost-saving configuration, since the
use of dedicated chain ports allow all of the switch's KVM ports to be utilized for
server connections – none of them need to be used for cascading. Your prior KVM
switch* investment is protected, since those switches can also be cascaded.
*CompatibleKVMSwitches:KH1508
A
/KH1516
A
/KN2116A/KN2124v/KN2132/
KN2140v/ KN4116/ KN4124v/ KN4132/ KN4140v
Dual Root Configuration
for Console Expansion
The advanced Dual Root function allows you to link two KM0932 switches to
achieve an 18 console configuration – letting you to expand the number of
consoles flexibly to fit your requirements. It’s an ideal solution for applications that
utilize multiple video displays, such as large data centers.
Non-blocked Access
All consoles connected to a master switch have simultaneous access to any server
on the same level, as well as having independent access to any server on the
installation.
Superior Video Quality
Matrix KVM Switches provide high video quality – 1280x1024 @60Hz up to 300
meters. The video signals are transmitted via Cat 5e/6 cable and maintain real-time
and true video quality. Auto Signal Compensation (ASC), assures optimum video
resolution over greater distances. In addition, an automatic skew compensation
function corrects color phase and timing errors that occur over long distance
transmissions – making a Matrix KVM Switch an excellent choice for video intensive
applications.
Port Access Control via
RS-232 Port
Each of the Console Modules has a built-in RS-232 port. Administrators can
establish a serial terminal login to the Console Module in order to control the KVM
port access for all consoles connected to switch – any console can be assigned to
access any KVM port from a single interface point. This function is extremely useful
in large data centers where the display of all the consoles can be projected onto a
wall for easy viewing of all operations, and the entire installation can be monitored
on a port-by-port basis
Audio enabled
The Matrix KVM Switch supports audio functions for multimedia-capable devices
connected with audio-capable adapter cables. Sound output and beeps from the
servers can be heard on the console’s speaker – allowing administrators to identify
and troubleshoot system problems at an early stage, minimizing repair costs.
Adapter ID
TheAdapterIDFunctionstoresportinformationsuchastheAdapterID,OS,
keyboard language, adapter name, operation modes, etc. It enables administrators
to relocate servers to different ports without having to reconfigure the adapters or
change the user authorization settings of the KVM switch.
