© Copyright 2015 ATEN® International Co., Ltd.
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd.
All rights reserved. All other trademarks are the property of their
respective owners.
Printed 11/2015 V3.0
VanCryst™ Professional A/V Solutions
VS0108HA
8-Port HDMI Splitter
Specifi cations
Features
DVD/Blu-ray Player
Output
Input
1 2 3 4 5 6 7 8
Output
Input
Output
Input
ATEN International Co., Ltd.
3F., No.125, Sec. 2, Datong Rd., Sijhih District., New Taipei City 221, Taiwan
Phone: 886-2-8692-6789 Fax: 886-2-8692-6767
www.aten.com E-mail: marketing@aten.com
The VS0108HA HDMI Splitter is the perfect solution for anyone
who needs to send one source of digital high defi nition video
to eight HDMI displays at the same time. It supports all HDMI-
enabled equipment, such as DVD players, satellite set-top boxes
and all HDMI displays.
The VS0108HA HDMI Splitter is HDCP (High Bandwidth Digital
Content Protection) compliant, making it effective for use with
all HDMI displays in home theater applications, as well as in
corporate, educational and commercial settings.
• Connects one HDMI source to eight HDMI displays at the
same time
• HDMI (3D, Deep, Color, 4kx2k); HDCP Compatible
• Supports resolutions of up to Ultra HD 4kx2k and 1080p
Full HD
• Features EDID Expert technology :
• EDID Library with default EDID confi gurations
• Built-in EDID Mode selection
• Copies a display's EDID to the source device
• Built-in bi-directional RS-232 serial control port for high-end
system control
• Supports Dolby True HD and DTS HD Master Audio
• Long distance transmission – up to 15 m (24 AWG)
• Supports up to 340MHz bandwidth for high performance
video
• Signaling rates up to 3.4 Gbits
• Plug-and-play – no software installation required
HDCP
HDMI
A/V In
HDMI
A/V Out
Ultra HD
Ultra HD
Function VS0108HA
Video Input
Interface 1 x HDMI Type A Female (Black)
Impedance 100
Ώ
Max. Distance 1.8 m
Video Output
Interface 8 x HDMI Type A Female (Black)
Impedance 100
Ώ
Video
Max. Data Rate 10.2 Gbps (3.4 Gbps Per Lane)
Max. Pixel Clock 340 MHz
Compliance HDMI (3D, Deep Color, 4K); HDCP Compatible
Max. Resolution
Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Max. Distance Up to 15 m
Audio
Input 1 x HDMI Type A Female (Black)
Output 8 x HDMI Type A Female (Black)
Control
RS-232
Connector: 1 x DB-9 Female (Black)
Baud rate and protocol:
Baud Rate: 19200, Data Bits: 8, Stop Bits:1,
Parity: No, Flow Control: No
EDID Settings EDID Mode:Default / Port 1 / Auto
Power
Connectors 1 x DC Jack
Consumption 5 VDC, 14.84W
Environmental
Operating Temperature 0-50 °C
Storage Temperature -20 - 60 °C
Humidity 0 - 80% RH, Non-Condensing
Physical Properties
Housing Metal
Weight 1.74 kg
Dimensions (L x W x H) 43.72 x 15.78 x 4.40 cm
RS-232
