VS0108HA RS-232 Control Tool
3
RS-232 Control Tool Operation
Overview
The VS0108HA’s built-in bi-directional RS-232 serial interface allows system
control through a high-end controller, PC, and/or home automation / home
theater software package. RS-232 serial operations in a VS0108HA installation
can be managed via a Graphical User Interface (GUI) on systems that are
running Windows. In order to use this Control Tool, two separate items of
software must be installed on all of the PCs in your installation – .NET
Framework 2.0 and the Control Tool AP. This procedure is detailed in the
following sections.
Before You Begin
.NET Framework 2.0
To install .NET Framework on your PC, do the following:
1. Download the executable file from the ATEN website or the Microsoft
Download Center online, and run it.
2. Follow the instructions on the screen. The installation applet will
automatically detect the operating system and install the correct drivers
Installing the RS-232 Control Tool
To install the RS-232 Control Tool, do the following:
1. Download the RS-232 Control Tool from the Download or VS0108HA’s
Resource page on our website:
www.aten.com
2. Save the file to a convenient location.
