ATEN International Co., Ltd.
3F., No.125, Sec. 2, Datong Rd., Sijhih District., New Taipei City 221, Taiwan
Phone: 886-2-8692-6789 Fax: 886-2-8692-6767
www.aten.com E-mail: marketing@aten.com
© Copyright 2014 ATEN® International Co., Ltd.
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd.
All rights reserved. All other trademarks are the property of their
respective owners.
Printed 03/2014 V2.0
VanCryst™ Professional A/V Solutions
VC182
VGA to HDMI Converter with Scaler
Specification
Features
The VC182 VGA to HDMI converter with Scaler offers an easy
and convenient way of converting VGA input signals into digital
video (HDMI). The VC182 carries a high-performing scaling
engine that converts the video resolution to give you the best
image quality.
You can operate the VC182 via the built-in On-Screen Display
(OSD), which can be controlled through accessible front panel
pushbuttons.
• Converts VGA signals to HDMI output
• Supports analog / digital audio
• Superior video quality – up to 1080p, 1920 x 1200
• Scaler - a premium scaling engine that converts various input
video resolutions into the display's native resolution, while
adjusts picture ratio automatically for maximum viewing
comfort
• 3D Deinterlacing - increases image clarity for ultimate viewing
quality by processing and scanning digital video signals
• Features a built in high-performance scaler function for best
image quality
• Features a superior de-interlacer function for smooth video
playback quality
• Built-in OSD function for video and system settings
confi guration
• Integrated superior video noise reduction
• Integrated next generation color engine – automatic picture
quality/color adjustment and enhancement
• Automatically detects video input signals
• LED indication of power status and source device
• No software required – eliminates incompatibility and
installation issues
• Device confi guration using a utility tool via mini USB port
• Supports 16:9 and 4:3 video aspect ratios
• Multiple selectable video resolutions
or
or
Function VC182
Connectors
Input
Video In 1 x HDB-15 Female (Black)
Digital
Coaxial
Audio
1 x RCA Female (Yellow)
Analog
Stereo
Audio
1 x mini stereo jack (Black)
Output HDMI Out 1 x HDMI Type A Female (Black)
Power 1 x DC Jack
Firmware Upgrade 1 x Mini USB Port
Switches
Down 1 x Pushbutton
UP 1 x Pushbutton
Menu 1 x Pushbutton
Firmware Upgrade 1 x Dip Switch
LEDs
Power 1 (Red)
Signal 1 (Green)
Video 1080p; 1920 x 1200
Power Consumption DC5V, 5W
Environment
Operating Temp. 0-40˚C
Storage Temp. -20~60˚C
Humidity 20~90% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.31 kg
Dimensions
(L x W x H)
11.00 x 8.30 x 2.80 cm
Video In
HDMI
A/V Out
OSD
Resolution
1920 x 1200, 1080P
Scaler
