Q170H4-M6 USER MANUAL
1
Brief Introduction
CPU
Specifications
•Intel
®
Q170 ChipsetChipset
• Dual-channel DDR4 memory architecture
• 4 x 288-pin DDR4 Long-DIMM sockets support up to 64 GB
• Supports 2133
MHz DDR4 Long-DRAM
Memory
• 2 x PCI Express x16 slots (one slot runs x16 Gen3, the other
runs x4 Gen3)
• 1 x PCI Express x1 Gen2 slot
• 1 x PCI slot
• 1 x M.2 slot(socket 3 key M 2242/2260/2280 ) for PCIE/SATA SSD
• Supported by Intel
®
Q170 Express Chipset
- 4 x Serial ATA 6Gb/s devices
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x VGA port
• 1 x DVI port
• 1 x HDMI port
• 1 x DP port
• 2 x USB 2.0 ports
• 4 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (1x Line in, 1x Line out, 1x Mic_in Rear)
Rear Panel I/O
• Intel WGI 219LM
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• LGA1151 socket for Intel
®
Skylake
Family Processors
Note: Please go to ECS website for the latest CPU support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 2 x 4-pin SYS_FAN connectors
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 4 x Serial ATA 6Gb/s connectors
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 2 x Serial port headers (COM)
• 1 x C-LINK header
• 1 x LPT header
• 1 x speaker header
• 1 x LDC header
• 1 x CLR_CMOS jumper
Internal I/O
Connectors &
Headers
• Realtek ALC662-VD0-GR & ALC 105 Amp
-
6 Channel High Definiton Audio Code
- Compliant with HD audio specification
Audio
LAN
Note: Please go to ECS website for the latest Menory support list.
