H110M4-C43(C33)/B150M4-C43 USER MANUAL

Brief Introduction

Specifications

CPU

• Intel

H110/B150 Chipset

Chipset

• Supported by Intel

H110/B150 Express Chipset

- 5 x Serial ATA 6Gb/s devices*

Storage

• LGA1151 socket for

Intel

Skylake processor

• Supports CPU up to 95W

Note: Please go to ECS website for the latest CPU support list.

• 1 x PS/2 mouse & PS/2 keyboard connector

• 1 x Serial port (COM1 port)

• 1 x HDMI port

• 1 x D-sub port (VGA port)

• 1 x DVI-D port

• 2 x USB 3.0 ports

• 1 x RJ45 LAN connector

• 2 x USB 2.0 ports

• 1 x Audio 6-ch jacks (line-in, line-out, microphone)

Rear Panel I/O

LAN

• Realtek RTL8111GN Gigabit Lan

• Realtek ALC662-VD0-GR 6-CH High Definition audio CODEC

- Compliant with HD audio specification

Audio

Internal I/O

Connectors &

Headers

• 1 x 24-pin ATX Power Supply connector

• 1 x 4-pin ATX 12V Power connector

• 1 x 4-pin CPU_FAN connector

• 1 x 4-pin SYS_FAN connector

• 1 x USB 3.0 header supports additional two USB 3.0 ports

• 2 x USB 2.0 headers support additional four USB 2.0 ports

• 5 x SATA 6Gb/s connectors*

• 1 x Front Panel audio header

• 1 x Front Panel switch/LED header

• 1 x Onboard parallel port header

• 1 x COM header (COM2)

• 1 x Clear CMOS jumper

• 1 x Trusted platform module header (TPM)

• 1 x Buzzer header

• 1 x Case open header

• 1 x ME disable header

Expansion

Slots

• 1 x PCI Express x16 Gen3 slot

• 2 x PCI Express x1 Gen2 slots

• 1 x PCI slot

• 1 x M.2 slot for 2280 SSD card (SATA only)*

• Dual-channel DDR4 memory architecture

• 2 x 288-pin DDR4 LONG DIMM sockets support up to 32 GB

• Supports DDR4 2133 MHz DDR4 SDRAM

Memory

Note: Please go to ECS website for the latest Memory support list.
