ECS Elitegroup 945GCD-I330 [11/48] Introducing the motherboard

Introducing the Motherboard

Table of Motherboard Components

LABEL COMPONENTS

1. SYS_FAN

System cooling fan connector

2. CLR_CMOS

Clear CMOS

umper

3. DDR2

240-pin DDR2 SDRAM slot

4. PWR_FAN Power coolin

fan connector

5. ATX1

Standard 24-pin ATX power connector

6. F_PANEL

Front panel switch/LED header

7. IDE

Primary IDE connector

8. SATA1~2

Serial ATA connectors

9. SPK Internal s

eaker header

10. PCI

32-bit add-on card slot

11. USBPWR_F

Front panel USB Power Select

umper

12. F_AUDIO

Front panel audio header

13. SPDIFO

SPDIF out header

14. F_USB1~2 Front panel USB headers

15. USBPWR_R Rear USB/PS2 Power Select jumper

This concludes Chapter 1. The next chapter explains how to install the motherboard.
