27
Using BIOS
Boot Other Device (Yes)
When enabled, the system searches all other possible locations for an operating
system if it fails to find one in the devices specified under the First, Second and Third
boot devices.
Press <Esc> to return to the main menu setting page.
ECS eJIFFY Function (Disabled)
Use this item to enable or disable the ECS eJIFFY Function. eJIFFY is ECS unique
software program for the quick access to the internet without entering O.S. Please
refer to eJIFFY Users’ Guide in the bundled DVD to know more about eJIFFY.
Removable Drives (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
Removable Drives
1st Drive 1st FLOPPY DRIVE
Help Item
Specifies the boot se-
quence from the available
devices.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Removable Drives
Press <Esc> to return to the Advanced Setup page.
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
CD/DVD Drives (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
CD/DVD Drives
1st Drive 1st FLOPPY DRIVE
Help Item
Specifies the boot se-
quence from the available
devices.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
CD/DVD Drives
Press <Esc> to return to the Advanced Setup page.
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
