ECS Elitegroup TIGD-CI3 (V1.0) [8/48] Introducing the motherboard
![ECS Elitegroup TIGD-CI3 (V1.0) [8/48] Introducing the motherboard](/views2/1212390/page8/bg8.png)
4
Introducing the Motherboard
• Intel
®
NM10 Express
• Onboard Intel
®
Dual Core Atom D525 processor
• DMI 667Mb/s
• Single-channel DDR3 memory architecture
• 2 x 204-pin DDR3 SODIMM socket support up to 4 GB
• Supports DDR3 800 DDR3 SDRAM
• 1 x PCI slot
• 2 x Serial ATAII devices
• ALC662 5.1ch High Definition audio
• Realtek 8103EL 10/100 Fast Ethernet Controller
• 1 x PS/2 keyboard & PS/2 mouse connectors
• 4 x USB ports
• 1 x optional parallel port
• 1 x VGA port
• 1 x COM port
• 1 x RJ 45 LAN connector
• 1 x Audio port
• 1 x 24-pin ATX Power Supply connector & 4-pin 12V con-
nector
• 2 x Serial ATA connectors
• 2 x USB 2.0 headers support additional 4 USB ports
• 1 x Clear CMOS header
• 1 x Front panel header
• 1 x Front panel audio header
• CPUFAN/SYSFAN connectors
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
• AMI BIOS with 8Mb SPI ROM
• Supports Plug and Play, STR/STD, Hardware monitor, PCI
interrupt selection, ACPI & DMI
System BIOS
Form Factor • Mini-ITX Size, 170mm x 170mm
CPU
Specifications
