Chapter 1
2
A75F2-M2 USER MANUAL
CPU
Specifications
• AMD A75 Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 UDIMM sockets support up to 32 GB
• Supports DDR3 1866/1600/1333/1066/800 MHz DDR3
SDRAM
Memory
• 1 x PCI Express x16 Gen2 slot
• 2 x PCI Express x1 slots
• 1 x PCI slot
• Supported by AMD A75 (Hudson D3)
- 6 x Serial ATA 6Gb/s connectors
Expansion
Slots
Storage
• 1 x PS/2 keyboard and mouse combo connector
• 1 x D-Sub port (VGA)
• 1 x HDMI port
• 1 x DVI port
• 6 x USB 2.0 ports
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, Line out, Mic_in Rear)
Rear Panel I/O
• Socket FM2 for AMD TRINITY processors
• Supports CPU up to 100W TDP
Note: Please go to ECS website for the latest CPU support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 1 x 3-pin PWR_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
(F_USB1 supports EZ Charger function)
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 6 x Serial SATA 6Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x SPDIF out header
• 1 x TPM header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Speaker header
• 1 x Parallel port header(LPT)
• 1 x Clear CMOS jumper
Internal I/O
Connectors &
Headers
• ALC662 6-Ch High Definition audio CODEC
- Compliant with HD audio specification
Audio
LAN
•
RTL8111E Gigabit Lan
• RTL8105E 10/100 LAN (optional)
Note: Please go to ECS website for the latest CPU support list.
