A75F2-M2 USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket FM2 for AMD TRINITY processors
2. SYS_FAN System cooling fan connector
3. CPU_FAN CPU cooling fan connector
4. DDR3_1~2 240-pin DDR3 SDRAM slots
5. ATX_POWER Standard 24-pin ATX power connector
6. SATA1~6 Serial ATA 6Gb/s connectors
7. F_PANEL Front panel switch/LED header
Front panel USB 2.0 headers
(F_USB1 supports EZ Charger function)
9. USB3F Front panel USB 3.0 header
10. PWR_FAN Power cooling fan connector
11. SPK Speaker header
12. CLR_CMOS Clear CMOS jumper
13. LPT Parallel port header
14. COM Serial port header
15. TPM Trusted Platform Module
16. CASE Case open header
17. PCIE1~2 PCI Express x1 slots
18. SPDIFO SPDIF out header
19. PCI 32-bit PCI add-on card slot
20. PCIEX16 PCI Express slot for graphics interface
21. F_AUDIO Front panel audio header
22. ATX12V 4-pin +12V power connector
8. F_USB1~2
