B85H3-M5 USER MANUAL

Chapter 4

Resetting disks to Non-RAID

An HDD that has been previously configured as part of another RAID set

in another platform is called a broken RAID HDD. When you install a broken

RAID HDD, you cannot select this disk when configuring a RAID set through

the Intel

Matrix Storage Manager option. If you still want to use this

broken RAID HDD as part of the RAID set configured through the Intel

Matrix Storage Manager, you may do so by resetting the disk to Non-RAID.

You will, however, lose all data and previous RAID configurations.

To reset disks to Non-RAID:

1. In the main Intel

Matrix Storage Manager RAID BIOS menu, highlight Reset

Disks to Non-RAID using the up/down arrow key then press <Enter>.

2. Use the space bar to select the HDD to reset to Non-RAID.

3. A dialogue box appears to confirm the action. Press <Y> to confirm;

otherwise, press <N>.

Pressing <Y> deletes all the data in the HDDs.

When you have finished, highlight Exit using the up/down arrow key then press

<Enter> to exit the Intel

Matrix Storage Manager RAID BIOS utility.

A dialogue box appears to confirm the action. Press <Y> to confirm; otherwise, press

<N> to return to the Intel

Matrix Storage Manager RAID BIOS menu.

Exiting Setup

[ Main Menu ]

1. Create RAID Volume 4. Recovery Volume Options

2. Delete RAID Volume 5. Acceleration Options

3. Reset Disks to Non-RAID 6. Exit

Pressing <Y> deletes all the data in the HDDs.

[ CREATE VOLUME MENU ]

Name Level Drives Capacity Status Bootable

Volume0 RAID0(Stripe) 2 931.5GB Normal Yes

[ ]Select [ESC]-Previous Menu [DEL]-Delete Volume

Intel(R) Matrix Storage Manager option ROM 11.0.0.1204

Deleting a volume will reset the disks to non-RAID.

WARNING: ALL DISK DATA WILL BE DELETED.

ALL DATA IN THE VOLUME WILL BE LOST!

Are you sure you want to delete “Volume0”? (Y/N):

[ DELETE VOLUME VERIFICATION ]
