Introducing the Motherboard
Table of Motherboard Components
7 IDE2 Secondary IDE connector
17 PCI-E2~3 PCI Express x1 Slots
9 JCMOS1 Clear CMOS jumper
11 PANEL1 Front panel switch/LED header
20 AUDIO2 Front panel audio header
21 PWR1 Standard 24-pin ATX power connector
LABEL COMPONENT
1 CPU Socket Socket 939 for AMD K8 processor
6 IDE1 Primary IDE connector
5 SATA1~SATA2 Serial ATA connectors
12 SIR1 Infrared header
13 FDD1 Floppy disk drive connector
15 PCI1~2 32-bit add-on card slots
16 AGPRO1 AGP Express graphics card slot
2 CPU_FAN1 CPU cooling fan connector
22 NB_FAN* Northbridge cooling fan connector
3 DIMM1~2 184-pin DDR SDRAM slots
18 CD1 CD-in header
This concludes Chapter 1. The next chapter explains how to install the motherboard.
4 USB2~3 Front Panel USB headers
10 SPK1 Speaker header
14 CNR1 Communications Networking Riser slot
8 SYS_FAN1 System cooling fan connector
19 PCI-E1 PCI Express x16 Slot
23 PWR2 4-pin +12V power connector
“*” stands for optional components and may not exist onboard.
