A960M-MV USER MANUAL
17
Chapter 2
ff
ff
fSATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Mode (IDE Mode)
Use this item to select SATA mode.
SATA Configuration
Serial-ATA Controller [Enhanced]
SATA Mode [IDE Mode]
SATA Port1 Not Present
SATA Port2 Not Present
SATA Port3 Not Present
SATA Port4 Not Present
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Serial-ATA Controller
Main Advanced Chipset M.I.B. III Boot Security Exit
Press <Esc> to return to the Advanced Menu page.
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Serial-ATA Controller (Enhanced)
Use this item to select Serial-ATA controller options: Disabled, Compatible, En-
hanced.
SATA Port 1~4 (Not Present)
This motherboard supports four SATA channel and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel.
