39
Using BIOS
Press <Esc> to return to the Chipset Menu page.
IGD Memory (64M)
This item shows the information of the IGD (Internal Graphics device) memory.
DVMT Memory (256M)
This item is used to select DVMT5.0 Total Graphic Memory size by the internal
Graphics Device.
IGD Multi-Monitor (Disabled)
This item enables or disables IGD (Internal Graphics device) multi-monitor.
System Agent Configuration
Scroll to this item and press <Enter> and view the following screen:
The chipset menu items allow you to change the settings for the North Bridge
chipset, South Bridge chipset and other system.
Chipset Menu
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
System Agent (SA)
Parameters
System Agent Configuration
PCH Configuration
ME Subsystem
Select which of IGFX/PEG/
PCI Graphics device
should be Primary Display
Or select SG for Switchable
Gfx.
System Agent Configuration
IGD Memory 64M
DVMT Memory 256M
IGD Multi-Monitor Disabled
