Introducing the Motherboard

Chapter 1

Introducing the Motherboard

Introduction

Thank you for choosing the H61H2-I2 motherboard. This motherboard is a high

performance, enhanced function motherboard designed to support the LGA1155

socket for

the latest Intel

Core

Family/Pentium

/Celeron

processors*

for high-

end business or personal desktop markets.

This motherboard is based on Intel

H61 Express Chipset for best desktop platform

solution. H61 is a single-chip, highly integrated, high performance Hyper-Threading

peripheral controller, unmatched by any other single chip-device controller. This

motherboard supports up to 16 GB of system memory with dual channel DDR3

1600

/1333/1066 SDRAM. It provides one PCI Express x1 slot for extending

usage. It implements an EHCI (Enhanced Host Controller Interface) compliant

interface that provides eight USB 2.0 ports (four USB 2.0 ports at the back panel and

two USB 2.0 headers support additional four USB 2.0 ports).

The motherboard is equipped with advanced full set of I/O ports in the rear panel,

including PS/2 mouse and PS/2 keyboard connectors, one DVI port (HDMI Port

Optional), one D-sub (VGA) port, one RJ45 LAN port, four USB 2.0 ports, and audio

jacks for microphone, line-in and line-out.

In addition, this motherboard supports four SATA 3.0Gb/s connectors for expansion.

*1 When accommodating Intel 3rd Generation CPU, the PCI Express 16X

slot can run at Gen3 speed, which accelerates on 32GB/s rate that effectively

delivers double of PCI Express Gen2 speed.

*2 The 3rd Generation CPU required.
