NVIDIA® Hybrid SLI® Technology Support
All in all, the NVIDIA SLI technology works.
This concludes Chapter 6.
2. Select the checkbox Enable SLI technology and then click Apply
You now have an NVIDIA
®
SLI-enabled PC!
You can also access these settings by opening the NVIDIA
®
Control Panel (right-
click on desktop), clicking on 3D Settings (shown below) and then selecting “SetSLI
configuration”.
Control Panel Setting of 2-Way SLI
