Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA1155 socket for 2
nd
Generation Intel
®
Core
TM
Family &
Unlock processors
2. CPU_FAN CPU cooling fan connector
3. SYS_FAN System cooling fan connector
4. DDR3_1~4 240-pin DDR3 SDRAM slots
5. ATX_POWER Standard 24-pin ATX power connector
6. SPK Internal speaker header
7. LDC Debug card header-for factory use only
8. SATA1~2 Serial ATA connectors (SATA1~2 support SATA 6Gb/s)
9. SATA3~6 Serial ATA connectors (SATA3~6 support SATA 3Gb/s)
10. F_PANEL Front panel switch/LED header
11. CASE CASE open header
12. F_USB2~3 Front panel USB headers
13. ME_UNLOCK ME unlock header-for factory use only
14. CLR_CMOS Clear CMOS jumper
15. F_USB1 Front panel USB header (F_USB1 supports EZ Charger)
16. USB3F Front USB 3.0 header
17. COM Onboard serial port header
18. PWR_FAN Power cooling fan connector
19. SPDIFO SPDIF out header
20. F_AUDIO Front panel audio header
21. PCIE1~3 PCI Express x1 slots
22. PCIEX16_S PCI Express slot for graphics interface
23. PCIEX16 PCI Express slot for graphics interface
24. ATX4P Auxiliary power connector for graphic card
25. ATX12V 8-pin +12V power connector
1. CPU Socket
