Q77H2-M

USER MANUAL

Chapter 1

• AMI BIOS with 64Mb SPI Flash ROM

• Supports Plug and Play, STR (S3) / STD (S4) , Hardware monitor

• Supports ACPI & DMI

• Audio, LAN, can be disabled in BIOS

• Supports Multi-Language

• F12 hot key for boot up devices option

• Supports Dual/Triple Display

System BIOS

Form Factor • Micro ATX Size, 244mm x 244mm
