39
Using BIOS
The chipset menu items allow you to change the settings for the North chipset,
South chipset and other system.
Chipset Menu
North Bridge
Scroll to this item and press <Enter> and view the following screen.
IGD Memory (64M)
This item shows the information of the IGD(Internal Graphics device) memory.
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F1:General Help
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
North Bridge Parameters
North Bridge
South Bridge
ME Subsystem
Main Advanced Chipset M.I.B III Boot Security Save & Exit
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F1:General Help
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
IGD Share Memory Sizw
North Bridge
IGD Memory [64M]
DVMT Mode Select [DVMT Mode]
DVMT/FIXED Memory [256MB]
PEG Force Gen1 [Disabled]
IGD Multi-Monitor [Disabled]
Main Advanced Chipset M.I.B III Boot Security Save & Exit
DVMT Mode Select (DVMT Mode)
This item allows you to select the DVMT operating mode.
DVMT/FIXED Memory (256MB)
When set to Fixed Mode, the graphics driver will reserve a fixed position of the
system memory as graphics memory, according to system and graphics requirements.
