ECS Elitegroup H67H2-I [6/82] Chipset
![ECS Elitegroup H67H2-I [6/82] Chipset](/views2/1212527/page6/bg6.png)
2
Introducing the Motherboard
Feature
The motherboard uses an LGA1155 type of Intel
®
Sandy Bridge processor that
carries the following features:
Processor
• LGA1155 socket for latest new Core i7/i5/i3/Pentium/Celeron high-end
desktop processors
• Supports “Hyper-Threading” technology CPU
• One x16 PCI Express Gen2 slot supporting up to 5 GB/s peak band-
width in each direction
“Hyper-Threading” technology enables the operating system into thinking it’s
hooked up to two processors, allowing two threads to be run in parallel, both on
separate “logical” processors within the same physical processor.
This board supports CPU up to equal or less than 95W TDP.
• Integrated SATA 3.0 Gb/s Host Controller
• Ten USB 2.0 ports supported
• Serial Peripheral Interface (SPI) support
• Enhanced DMA Controller, interrupt controller, and timer functions
• Integrated Graphics Support with PAVP 1.5
The Intel H67 Express Chipset is a single-chip with proven reliability and per-
formance.
Chipset
Memory
• Supports DDR3 1333/1066 DDR3 SDRAM with Dual-channel architec-
ture
• Accommodates two unbuffered DIMMs
• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB
Onboard LAN (optional)
• Supports PCI Express
TM
1.1
• Integrated 10/100 transceiver
• Wake-on-LAN and remote wake-up support
• Supports PCI Express
TM
1.1
• Integrated 10/100/1000 transceiver
• Wake-on-LAN and remote wake-up support
