Chapter 2

Z77H2-A3D USER MANUAL

2-4-5. Connecting Optional Devices

Refer to the following for information on connecting the motherboard’s optional

devices:

No. Components No. Components

1 USB3F 5 ME_UNLOCK

2CASE6COM

3 SATA1~6 7 SPDIFO

4 F_USB1~2 8 F_AUDIO
