ECS Elitegroup A875M-A [10/74] Introducing the motherboard
![ECS Elitegroup A875M-A [10/74] Introducing the motherboard](/views2/1212546/page10/bga.png)
6
Introducing the Motherboard
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket
Socket for AMD Phenom
TM
II/Athlon
TM
II/Sempron
TM
processors (socket AM3)
2. CPU_FAN
CPU cooling fan connector
3. DDR3_1~4
240-pin DDR3 SDRAM slots
4. ATX_POWER
Standard 24-pin ATX power connector
5. PWR_FAN
Power cooling fan connector
6. SATA1~5
Serial ATA connectors
7. USBPWR_F1~2
Front panel USB power select jumpers
8. F_PANEL
Front panel switch/LED header
9. SPK
Speaker header
10. F_USB1~4
Front Panel USB headers
11. CLR_CMOS
Clear CMOS jumper
12. SYS_FAN
System cooling fan connector
13. SPDIFO
SPDIF out header
14. F_AUDIO
Front panel audio header
15. PCI1~3
32-bit add-on card slots
16. PCIEX16
PCI Express x16 slot for graphics interface
17. PCIE1~2
PCI Express x1 slots
18. USBPWR_R1~2
Rear USB/PS2 power select jumpers
19. ATX12V 8-pin +12V power connector
This concludes Chapter 1. The next chapter explains how to install the motherboard.
