KEY FUNCTIONS
START/STOP
switches the appliance ON and OFF (timer 124.28841... only)
1/2 LOAD
with timers VD50/VD51, reduces the number of rinses from 4 to 3 in
COTTON cycles; with timers VD52/VD53, reduces the number of rinses
from 3 to 2 in COTTON cycles.
SUPER RINSE
increases the water fill in the second and third rinses in COTTON cycles
(first and second rinses for timers VD51/VD52).
ECONOMY
reduces the washing temperature to 60°C in the 95°C COTTON
programmes (the duration of the programme remains unaltered).
COTTON 90°
in models with fixed-temperature thermostats, performs the heating phase
in COTTON cycles (n° 1 and 2) at 90°C instead of 60°C.
SELECT TEMPERATURE
30° - 40° - 60° - 90°
in models with fixed-temperature thermostats, these keys are used to select
the washing temperature.
COLD WASH
in models with fixed-temperature thermostats, disconnects the power supply
to the heating elements.
RINSE HOLD
stops the appliance leaving water in the tub at the end of the final rinse (in
cycles for SYNTHETICS, DELICATES and WOOL). If a jumper is fitted
between timer contacts H2.1 and H2.2, this option can also be selected in
cycles for COTTON.
By pressing this button again, the programme is completed with the drain
and spin phase.
DELICATE SPIN
the function of this key is opposite to that of the "RINSE HOLD" key.
NO SPIN
excludes all the spin phases
REDUCED SPIN
reduces the spin speeds as shown in the table below. The two different
types of reduced spin depend on the way in which the electronic control
board is connected.
SPIN SPEED SELECTOR
reduces the speed in the final spin as shown in the table below.
POSITION OF
SELECTOR
07654321
REDUCTION KEY Type 2 Type 1
SPIN C1 (rpm) 600
500 460 420
380
340
300
0
800
700 600 500
400
350
300
0
900
800 700 600
500
400
300
0
1000
900 800 700
600
500
300
0
SPIN C2 (rpm) 540
500 460 420
380
340
300
0
SPIN C3 (rpm) 740
500 460 420
380
340
300
0
TSE-P 08/98 eb 12/17 599 33 62-25/9
