31
English
J3710-ITX
J3160-ITX
4.3 Advanced Screen
In this section, you may set the congurations for the following items:
CPU Conguration, Chipset Conguration, Storage Conguration, IntelRMT Con-
guration, Super IO Conguration, ACPI Conguration, USB Conguration and
Trusted Computing.
Setting wrong values in this section may cause the system to malfunction.
