22
English
ATX 12V Power
Connector
(4-pin ATX12V1)
(see p.6, No. 1)
is motherboard
provides an 4-pin ATX
12V power connector.
Serial Port Header
(9-pin COM2)
(see p.6, No. 18)
is COM2 header
supports a serial port
module.
TPM Header
(17-pin TPMS1)
(see p.6, No. 17)
is connector supports Trusted
Platform Module (TPM) system,
which can securely store keys,
digital certicates, passwords,
and data. A TPM system also
helps enhance network security,
protects digital identities, and
ensures platform integrity.
Print Port Header
(25-pin LPT1)
(see p.6, No. 16)
is is an interface
for print port cable
that allows convenient
connection of printer
devices.
CCTS#1
RRTS#1
DDSR#1
DDTR#1
RRXD1
GND
TTXD 1
DDCD#1
1
RRI#1
1
GN D
SM B_DATA_MAIN
LA D2
LA D1
GN D
S_ PWRDWN #
SE RIRQ #
GN
D
P CICL K
P CIRST #
LA D3
+3 V
LA D0
+3VS B
GN D
FR AM E
SM B_CLK_MAIN
1
AF D#
ER ROR#
PI NIT#
GN D
SL IN#
ST B#
SP D0
SP D1
SP D2
SP D3
SP D4
SP D5
SP D6
SP D7
AC K#
BU SY
PE
SL CT
