STATUS SP300 [2/11] Page 2
![STATUS SP300 [2/11] Page 2](/views2/1214040/page2/bg2.png)
SP300
C
D
3
2
1
Round pattern
Horizontal pattern
Vertical pattern
SP300
E
F
1
1
2
Even coat troughout
CORRECT
INCORRECT
Light coat Heavy coat Light coat
4
1" - 12"
Содержание
- Page 1 1
- Page 2 2
- General safety rules 3
- Page 3 3
- General safety rules 4
- Page 4 4
- Specific safety rules 4
- Functional description 4 prepare to use 5
- Page 5 5
- Specific safety rules 5
- Page 6 6
- Spraying 6
- Spraying 6 cleaning 6
- Attach the cup to the gun and plug in the sprayer 6 spray the solution through the gun for two seconds in a safe area spray again for two seconds unplug the spray gun and trigger the spray gun so that the material inside the spray gun flows back into the container 7 wipe the exterior of the cup and gun until clean 8 unscrew the nut and remove the air cap and nozzle fig g 1 9 clean the container suction tube air cap and nozzle with a cleaning brush and the appropriate cleaning solution never clean nozzle or air holes in the spray gun with sharp metal objects do not use solvents or lubricants containing silicone 10 turn both knobs on both sides of the air compressor assembly to the unlock position pull and separate the spray gun from the air compressor assembly fig g 2 11 clean the rear of the spray gun with the appropriate cleaning solution turn the suction tube anti clockwise and pull the suction tube downward to disassemble it from the spray gun then clean the suction tube with the ap 7
- Maintenance 7
- Page 7 7
- Power 400w voltage 220 240v spraying pressure 0 1 0 2 bar delivery rate 140 g min max viscosity 30 din s weight 1 45kg 7
- Technical data 7
- Trobleshooting 7
- Troubleshooting 7
- Unplug the spray gun move off the external filter cover 1 with a tool such as a flat screw driver 2 move off the inner filter cover 2 3 remove the dirty filters 3 and replace with new ones 7
- You should inspect the air filter in the air compressor assembly to see if it is excessively dirty if it is dirty follow the steps see fig h to replace it 7
- Page 8 8
- Основные правила безопасности 8
- Page 9 9
- Описание 9
- Подготовка к работе 9
- Специальные правила безопасности 9
- Page 10 10
- Подготовка к работе 10
- Работа 10
- Page 11 11
- Комплектация 11
- Технические характеристики 11
- Чистка и обслуживание 11
